Elevate Your Tone to the Next Level
Your tone is only as strong as its foundation. The ZUTA CORE is a professional dual-stage guitar booster designed to be seamlessly built directly into your instrument. It's not just a boost—it's the heart of your sound.
Hidden Power, Unmatched Clarity
With a discreet push-pull potentiometer, you can instantly switch from a clean bypass to a powerful analog mid-frequency boost. This isn't just a volume bump; it's a meticulously crafted circuit that brings out clarity, sustain, and presence, ensuring your solos and riffs always cut through the mix.
Always On, Always Ready
Powered by a single 9V battery, the ZUTA CORE is a studio-grade preamp that lives inside your guitar, giving you professional-level tone shaping whenever you need it. No extra pedals, no messy cables—just pure, powerful sound, always at your fingertips.
FROM CLEAN TO CUTTING EDGE
Download the User Manual
FEATURES
Product Specific
• Dual-stage analog booster circuit;
• Integrated push-pull potentiometer for ON/OFF switching;
• Transparent boost with string separation intact;
• Powered by standard 9V battery;
• Pre-wired connector for easy installation.
Series Specific
• Compact module designed for direct guitar installation;
• Solid-soldered PCB with no fragile connectors inside;
• High headroom to handle passive and active pickups;
• Ultra-low noise and wide bandwidth;
• True analog signal path, no compression.
Brand Specific
• Laser-engraved ZUTA CORE casing;
• Studio quality boost inside your instrument;
• Easy to install, battery replaceable;
• Built for both stage and studio reliability.
SPECIFICATIONS
• Input Impedance: 1 MΩ;
• Output Impedance: 1 KΩ;
• Nominal Input Level: up to +20 dBu;
• Recommended Load: 10 KΩ or higher;
• Boost (approx.): 20 dB
• Power: 9V battery, ~500 h battery life depending on usage;
• Weight: <100 g (module + pot).
WIRING OVERVIEW
ZUTA CORE connects directly to your instrument’s existing controls:
• Input from pickup selector or tone pot middle pin;
• Output to guitar jack;
• Ground to pickguard/shielding;
• Powered by 9V battery (standard clip).
The pre-wired connector simplifies installation and ensures long-term reliability.
